Max Light MODERN

Scandinavia Windows > Systems > Window and door systems > Max Light > Max Light MODERN
  • a window system with thermal insulation, featuring a smooth and slim profile line
  • the specific shape of the profiles (resembling steel profiles) gives the structure a modern industrial character
  • system application: fixed windows, opening windows: single- or double-sash windows with tilting, opened inwards
  • the system features slim profiles with the minimum visible width and modern design
  • a wide range of colours – RAL palette (Qualicoat 1518), texture colours, Aliplast Wood Colour Effect (wood-like colours), Aliplast Loft View – colours imitating stone surfaces (Qualideco PL-0001), anodised colour (Qualanod 1808), bi-colour
360 view
Leaflet Max Light

TECHNICAL SPECIFICATION

SYSTEMMATERIALMINIMUM VISIBLE WIDTH INWARD OPENING WINDOWMINIMUM VISIBLE WIDTH INWARD OPENING DOORMINIMUM VISIBLE WIDTH OUTWARD OPENING DOORINSTALLATION DEPTH FRAMEINSTALLATION DEPTH SASHREBATE HEIGHTGLASS THICKNESS
Max Light MODERNaluminium/polyamidframe: 35 mm
sash: 35 mm		frame: 35 mm
sash: 68 mm		frame: 15 mm
sash: 88 mm		75 mm84 mm15 mmup to 68 mm

PERFORMANCE

SYSTEMTHERMAL INSULATION UF*

AIR PERMEABILITY

WINDLOAD RESISTANCE

WATERTIGHTNESS
MAX LIGHTUf from 1,8 W/m2KClass 4; EN 12207 Class C5; EN 12210Class E1650; EN 12208

*Thermal insulation is dependent on a combination of profiles and thickness of the filling
