Imperial SU

Scandinavia Windows > Systems > Window and door systems > Imperial > Imperial SU
  • three-chamber window system with thermal insulation designed for designing windows with hidden sash, invisible from the outside
  • the system features specially designed shape of the frame hiding the full height of sash profile
  • a wide range of glazing allows using all types of single and double cavity, acoustic and anti-burglary glass panes
  • profile drainage in two variants: traditional and hidden
  • the option of bending profiles (detailed specification of profiles and detailed technical parameters of profile bending process are available in the customer area of the website www.aliplast.pl)
  • hidden sash system is the system preferred by designers, as it allows “hiding” windows in aluminium and glass structure; thanks to application of this solution opened and fixed window segments look identical from the outside
  • a wide range of colours – RAL palette (Qualicoat 1518), texture colours, Aliplast Wood Colour Effect (wood-like colours), Aliplast Loft View – colours imitating stone surfaces (Qualideco PL-0001), anodised colour (Qualanod 1808), bi-colour
360 view
Leaflet Imperial SU

TECHNICAL SPECIFICATION

SYSTEMMATERIAL

DEPTH OF FRAME

DEPTH OF LEAF

GLAZING RANGETYPE OF WINDOWS
IP SUaluminium / poliamid65 mm68 mm4-41 mm

hidden sash

IP SU ialuminium / poliamid65 mm68 mm4-41 mm

hidden sash

PERFORMANCE

SYSTEMTHERMAL INSULATION UF*

 AIR PERMEABILITY

WINDLOAD RESISTANCE

WATERTIGHTNESS
IP SUUf from 1,63 W/m2KClass 4; EN 12207Class C5; EN 12210Class E1200; EN 12208
IP SU iUf from 1,27 W/m2KClass 4; EN 12207Class C5; EN 12210Class E1200; EN 12208

*Thermal insulation is dependent on a combination of profiles and thickness of the filling
